Zoom GFX8 Guitar Effects Processor
No longer available at zZounds
zZounds Gear Experts Say...
160 factory patches. 80 user presets.
Overview
This is Zoom's all-new, top-of-the-line guitar box, with a metal case for onstage use and abuse. Besides the VAMS (Zoom's Variable Architecture Modeling System) amp and preamp emulations, there are 69 effect types - use up to 9 at once! The "Easy Edit" knobs and MIDI implementation make live and studio use a breeze. There are 160 built-in Zoom patches and 80 user programmable patches.
This is a Zoom product, so you know there are still more features. How about a 25 second phrase sampler? The sampler also has a mode called "Jam Play," which lets you record 12 seconds of audio and play it back at a slower speed - without changing the pitch! Cool!
When you factor in the built-in expression pedal and the large LED display, you have a formidable tool for making some awesome guitar sounds. This box is for all guitarists looking for a multi-effects pedal.
Features
VAMS (Variable Architecture Modeling System).
69 Effects types - up to 9 at once.
New! Sophisticated Distortion technology can duplicate the sound of guitar amps and preamps.
Intuitive "Easy Edit" knobs for live performace.
MIDI in and out.
Edit and manage patches with supplied software for Windows 95/98 or Macintosh OS.
160 built-in Zoom patches/80 user programmable patches.
25-second phrase sampler/12-second Jam Play feature. You can alter the speed of your samples without changing the pitch.
Rugged all metal chasis designed specifically for on stage use.
Built-in expression pedal.
Large, easy-to-read LED… read more display. read less
This is a Zoom product, so you know there are still more features. How about a 25 second phrase sampler? The sampler also has a mode called "Jam Play," which lets you record 12 seconds of audio and play it back at a slower speed - without changing the pitch! Cool!
When you factor in the built-in expression pedal and the large LED display, you have a formidable tool for making some awesome guitar sounds. This box is for all guitarists looking for a multi-effects pedal.
Features
VAMS (Variable Architecture Modeling System).
69 Effects types - up to 9 at once.
New! Sophisticated Distortion technology can duplicate the sound of guitar amps and preamps.
Intuitive "Easy Edit" knobs for live performace.
MIDI in and out.
Edit and manage patches with supplied software for Windows 95/98 or Macintosh OS.
160 built-in Zoom patches/80 user programmable patches.
25-second phrase sampler/12-second Jam Play feature. You can alter the speed of your samples without changing the pitch.
Rugged all metal chasis designed specifically for on stage use.
Built-in expression pedal.
Large, easy-to-read LED… read more display. read less
Specs
Effect Programs: 69 (67 effects + amp simulator + ZNR)
Effect Modules: 4 modules + amp simulator + ZNR
Sampler Function: 25 sec max. recording time, playback speed control
User Patch Memory: 20 banks x 4 = 80 (read/write)
Preset Patch Memory: 40 banks x 4 = 160
Sampling Frequency: 40 kHz
A/D Conversion: 20-bit, 64x oversampling
D/A Conversion: 20-bit, 128x oversampling
Input: Standard monaural phone jack
Input Impedance: 470 kilohms
Nominal Input Level: -10 dBm
External Return: standard monaural phone jack
Return Impedance: 470 kilohms
Return Input Level: -10 dBm
Aux In: Mini stereo phone jack
Aux Input Impedance: 10 kilohms
Aux Reference Input Level: -10 dBm to +4 dBm
Line Output: Standard monaural phone jack x 2 = stereo
Rated Line Output level: +4 dBm
Line Output Load Impedance: 10 kilohms or more
Headphone Output: Standard stereo phone jack
Rated External Send Output Level: -10 dBm
External Send Output Load Impedance: 10 kilohms or more
Control Connectors: MIDI Out, MIDI In
Display: 8-digit alphanumeric LED display, 2-digit 7-segment LED display
Power Requirements: 12 V AC (from supplied AC adapter AD-0008)
Dimensions (W x D x H): 455 x 203 x 80mm
Weight: 3.6 kg
Effect Modules: 4 modules + amp simulator + ZNR
Sampler Function: 25 sec max. recording time, playback speed control
User Patch Memory: 20 banks x 4 = 80 (read/write)
Preset Patch Memory: 40 banks x 4 = 160
Sampling Frequency: 40 kHz
A/D Conversion: 20-bit, 64x oversampling
D/A Conversion: 20-bit, 128x oversampling
Input: Standard monaural phone jack
Input Impedance: 470 kilohms
Nominal Input Level: -10 dBm
External Return: standard monaural phone jack
Return Impedance: 470 kilohms
Return Input Level: -10 dBm
Aux In: Mini stereo phone jack
Aux Input Impedance: 10 kilohms
Aux Reference Input Level: -10 dBm to +4 dBm
Line Output: Standard monaural phone jack x 2 = stereo
Rated Line Output level: +4 dBm
Line Output Load Impedance: 10 kilohms or more
Headphone Output: Standard stereo phone jack
Rated External Send Output Level: -10 dBm
External Send Output Load Impedance: 10 kilohms or more
Control Connectors: MIDI Out, MIDI In
Display: 8-digit alphanumeric LED display, 2-digit 7-segment LED display
Power Requirements: 12 V AC (from supplied AC adapter AD-0008)
Dimensions (W x D x H): 455 x 203 x 80mm
Weight: 3.6 kg
Documents and Manuals
For support or warranty questions, please contact the manufacturer:
Phone: 631-542-5270
Email: info@zoom-na.com
Web: https://zoomcorp.com/en/us/contact/
Phone: 631-542-5270
Email: info@zoom-na.com
Web: https://zoomcorp.com/en/us/contact/
Reviews
Reviewers gave this product an overall rating of 5 out of 5 stars.
(297 ratings)
Submitted April 29, 2004 by a customer from aol.com
"Great sounds, great capabilities, CREATE YOUR OWN SOUND!!"
2 years owning it, haven't looked for any replacement. Great for playing gigs. Stands exactly where it should because of its weight. So you won't be dragging it when walking around. The power plug is really good because while it does have htat big black box for it, it the actual 2 prong thing comes out through an extention from it. Great sounds, great capabilities, CREATE YOUR OWN SOUND!!
Sound
Awesome sound comming out of this beast. It takes a while to get exactly what you want, but thats the thing your getting exactly what you want so it's worth the time.
Features
Great MIDI stuff. Wonderful for transfering patches and what not. Also get the best sound from this by tweeking it to the decimal.
Quality
GREAT!! Looks like a monster. I mean all metal construction. And it has this nifty grip thing on the pedal that I think you can like take it off to rinse. But it'll never come off while playing. My pedal is on its second owner and it's holding up perfect.
Value
It's worth every penny you'll invest in it. It sounded great through a lil 10 watt amp, and it sounds wonderfull out of a 120 watt. It's unbeatable.
Manufacturer Support
Support is great. The reason it is, is because I never needed it. Not one problem in two years owning it.
The Wow Factor
Oh well sex appeal towards it is great. Listening to the demo off the cd thats included will make you love it without touching it.
Musical Style:
Metal
7 of 8 people (88%) people found this review helpful. Did you?
