JMAZ Professional Centipede B4 Effect Light

Overview

The JMAZ Professional Centipede B4 is a cutting-edge LED Active Wave Bar designed to elevate your lighting setups with its dynamic features and exceptional performance. The Centipede B4 offers versatility, precision, and stunning visual effects, making it an ideal choice for professional lighting applications in theaters, concerts, events, and more.

At the heart of the Centipede B4 are 4 high-intensity 60W RGBW LEDs, each equipped with infinite 360* degrees tilt heads. This unique design allows for unmatched flexibility and creativity in directing light beams precisely where needed, ensuring optimal coverage and captivating visual effects.

Adding to its versatility, the Centipede B4 features 4 rings of 120 RGB SMDs (Surface Mount Devices) for full pixel mapping capabilities. With this feature, you can create intricate patterns, animations, and dynamic color effects with precision and ease, adding depth and dimension to your lighting designs.

With a narrow beam angle of 3.5*, the Centipede B4 delivers concentrated and defined light beams, perfect for highlighting specific elements or creating dramatic effects. Whether used as a wash light, beam fixture, or effect light, it offers exceptional versatility to suit a wide range of lighting applications.

Equipped with comprehensive control options, including DMX512, Art-Net, and TBD DMX channels, the Centipede B4 ensures seamless integration into any lighting setup. Its linear LED dimmer allows for smooth dimming from 0% to 100%,… read more while the adjustable CTO (Correlated Color Temperature) range of 2500K to 8000K provides precise color temperature control to match any environment.

Additionally, the Centipede B4 features a variable strobe shutter with a frequency range of 1 to 25 Hz, allowing you to create dynamic strobe effects with adjustable speed to suit your desired atmosphere.

With an IP rating of 20, the Centipede B4 offers reliable performance in indoor environments, while its TRUE1 power connection ensures secure and reliable power supply. Furthermore, it is CE and ETL listed, guaranteeing compliance with international safety and quality standards.

In summary, the JMAZ Professional - Centipede B4 is a state-of-the-art lighting fixture that combines powerful illumination, precise control, and versatile functionality, making it an indispensable tool for lighting professionals seeking to create unforgettable visual experiences.

Features:

- Versatile Lighting: Equipped with an 4 x 60W RGBW LED Engine and 120 x 0.2W RGB SMD LEDs, providing a wide range of lighting options for any setting. Eight individually controllable tilting heads offer either 360-degree continuous or 240-degree movement.
- Advanced Color Control: Utilizes RGBW color mixing with 16-bit precision and linear 16-bit color temperature control ranging from 2500K to 8000K, offering precise and vibrant color options.
- Pixel Mapping Capability: Allows for individual pixel control on each LED, enabling intricate and dynamic lighting designs.
- Reliable Connectivity: Equipped with Seetronic Powercon IP65 True1 connectors for power input and output, along with Seetronic 5-pin XLR and etherCON data connectors for reliable data transmission.
- Precise Control: Compatible with multiple control protocols including DMX, Art-Net, RDM, and sCAN, offering flexibility and ease of use.
- Certified Quality: cETLus Listed, CE, and FCC certified, with an IP Rating of 20, ensuring compliance with safety and quality standards.
- Comprehensive Built-in Effects: Delivers an array of sophisticated effects, encompassing virtual colors and movement macros with foreground and background color control, facilitating effortless pixel animation effects.

Specs

- Light Source:
- 4 x 60W RGBW LED Engine
- 120 x 0.2W RGB SMD LED (30 LEDs per Head)
- LED Life Expectancy: 50,000 Hours
- Color System:
- RGBW color mixing 16 bit
- Linear 16bit color temperature (range) 2500 -8000K
- Pixel Mapping capability with individual pixel control on each LED
- Dynamic RBG color Marcos for Eye-candy (Outer Ring)
- Body:
- Die-cast Aluminum and Steel structure with high impact flame retardant PA6 GF 30 (Polyamide 6) with 30% glass fiber
- Exterior finish: Black
- Electronics:
- Linear LED Dimmer: 0-100% Smooth
- Linear CTO: 2500-8000K
- Strobe Shutter: 1-25 Hz Variable
- Electrical:
- Input Voltage: 100 - 240V AC, 50/60Hz (Auto ranging with active PFC)
- Power Consumption: 320W
- Power Linking for connecting fixture in daisy-chain
- Up to 6 units @110V with a 20A circuit
- Up to 12 units @208V with a 20A circuit
- Up to 12 units @230V with a 20A circuit
- Fuse: F12A, 250V
- Certification / Qualifications
- cETLus Listed, CE, FCC
- IP Rating: IP 20
- Operating Temperature: 40 * C ( 104 *F)
- Minimum Temperature: - 10 * C ( 14 * F)
- Maximum Temperature: 60 * C ( 140 * F)
- Optics: Beam Angle:3.5*
- Dynamic Effect:
- Movement:
- Tilt: 2 modes
- 360-degree continuous movement
- 240-degree ( 8 bit and 16 bit)
- Selectable preset home position Macros by DMX function channel for fast and easy programming
- Selectable fast and precise movement speed by DMX function channel
- Scan position memory with automatic tilt position correction
- Dimmer: 0 - 100% smooth linear electronic dimming
- Shutter/ Strobe
- High speed electronic shutter and strobe
- 0-25Hz shutter/ strobe effect with variable speed
- Preset pulse strobe effect with variable speed
- Random strobe effect with variable speed
- Sharp Beam Effect
- Dynamic Ring Effect with built-in Macros with variable speed
- Control:
- Control Protocol: DMX, Art-Net, RDM, sCAN
- Personalities: 3 modes: 21/39/61 Control Channels
- Physical:
- IP Rating: 20
- Cooling: Fan
- Power Connection: US Edison (UL listed) plug to Seetronic Powercon IP65 True1
- Power Input: Seetronic Powercon IP65 True1
- Power Output: Seetronic Powercon IP65 True1
- Data Connectors: Seetronic 5pin XLR; Seetronic etherCON
- Cable Length: Power 5 feet (1.5 meter); DMX 5 feet (1.5 meter)
- Dimensions: 23.7\0x2033 x 9.3" x 6.6"
- Weight: 22 lbs.
- Box Content:
- 1 x Centipede B4
- 1 x Powercon IP65 TRUE1 Power cable
- 1 x 5 pin DMX Cable
- 1 x User Manual
- 2 x Omega Brackets
- 1 x Safety Cable

Dimensions and Weight in Packaging
Base Item: Shipping Weight: 31.3 lbs; Shipping Dimensions: 24 x 9 x 5 in; Manufacturer Part Number (MPN): JP1001
